Procedure
1Clickinanyviewtomakeitactive.
Theactiveviewisidentiedwithathickerborder.
2OpentheActivemenu.
3SelectAGC(AutomaticGainControl).
4Selectavaluefromtheoptionsprovided.
Thechoiceyoumakeisbydefaultonlyappliedtothecurrentlyselected(active)
view.
Selectthemiddleofthebuttontoopenasmallmenuwiththeavailableoptions.
Selecttheleftsideofthebuttontoselecta"lower"'menuchoice.Selecttheright
sideofthebuttontoselecta"higher"'menuchoice.
Relatedtopics
Improvingtherecognitionofshandschoolsusingreceiverlters,page72
ReducingpropellernoiseandinterferencewiththeNoise
Filter
Unlessyousynchronizethetransmissionsfromyourotherhydroacousticsystemsyou
mayhaveanissuewithinterference.Evenwithsynchronizationactivatedthenoise
fromothernearbyvesselsmaycausenoise.
Context
TheNoiseFilterisusedtominimizetheinterferencefromotheracousticssystems(sonars
andechosounders)onyourownand/orothervessels.Thelteralsosuppressesnoise
fromyourpropellers,andfromothersimilarnoisesources.TheNoiseFilterisvery
effectiveifyouarebotheredbystrongnoiseorinterference,especiallyfromyourown
vessel,orevenfromothervesselsoperatingnearyou.
Tip
Useweakltering-orturnthelteroff-ifyouhavestrongechoesonshortranges.The
ltermaythenbetoopowerful,anddistorttheechopresentation.
TheltersintheSU90areimplementedin“series”.Thenoiselteringisdoneintwo
stagesearlyinthereceiverprocess.
Procedure
1Clickinanyviewtomakeitactive.
Theactiveviewisidentiedwithathickerborder.
SimradSU90OperatorManual
