Displaymenu
TheDisplaymenuprovidesbasicfunctionsrelatedtothescreenbehaviourand
presentationofSU90data.
Howtoopen
SelecttheDisplayicon.
TheiconislocatedundertheMainmenu.Selectthe
icononemoretimetoclosethemenu.
Description
Onlybriefdescriptionsareprovided.Fordetailed
informationabouteachfunctionanddialogbox,refer
totheSU90Referencemanualorthecontextsensitive
on-linehelp.
Tip
Ifyoudonotneedtousethemenusystem,youcanhide
it.ThisallowsmorespacefortheSU90presentation.
UseMenuonthetopbartohideorshowthemenu.
Whenthemenusystemishidden,itappearstemporarilyontheleftorright
handsideofthescreenifyoumovethecursortothatposition.
ThechoicesinthethismenudependsonwhichviewintheSU90presentationthatis
currently"active".Themenumaythereforechangefromoneviewtoanother.The
screencapturemaynotshowyouallthemenuchoices.
•VisualObjects
VisualObjectsisan"on/off"buttonusedtoopentheVisualObjectsmenu.TheVisual
Objectsmenucontrolswhichgraphicalelementsthatareshowninthedifferentviews.
Thesegraphicelementsincludemarkers,vectorsandtargetsthataretracked.The
majorityofthefunctionsare"on/off"buttonstoenableordisablethesegraphic
elementsintheSU90views.
VisualObjectsmenu,page157
•Cosmetics
UsethefunctionsontheCosmeticsmenutoturn"cosmetic"elementsintheSU90
presentationonoroff.Themajorityofthefunctionsareon/offbuttonstoenableor
disable"cosmetic"elementsintheSU90presentation.Thisfunctionisnotavailable
inalltheviews.
Cosmeticsmenu,page160
Menusystem
