Simrad SU90 User Manual

114
381291/C
aSettheswitchtopositionLOWER.
LoweringisautomaticallystoppedwhentheLowerLimitSwitchisactivated.
Ifnecessary,thetransducercanbestoppedinanypositionbysettingthe
Hoist/LowerSwitchtoSTOP.
bSettheswitchtopositionSTOP.
5Hoistingthetransducer:
aSettheswitchtopositionHOIST.
HoistingisautomaticallystoppedwhentheUpperLimitSwitchisactivated.
Ifnecessary,thetransducercanbestoppedinanypositionbysettingthe
Hoist/LowerSwitchtoSTOP.
bSettheswitchtopositionSTOP.
6LocatetheHoist/LowerSwitch(S302).SettheswitchtopositionREMOTE.
Note
FornormaloperationfromtheOperatingPanel,theswitchmustbesettoREMOTE.
7Closethecabinetdoor.
Relatedtopics
Loweringandhoistingthetransducerfromthesonarroom,page112
SimradSU90OperatorManual
