Simrad SU90 User Manual

116
381291/C
bRemovethehandcrankfromitsstorageposition.
cRemovetheplasticplugonthetopcoverofthehullunit.
dMountthehandcrankontothestubshaftthroughtheholeinthetopcover.
eLocatethebrakereleasescrewonthemotor.
fUsean4mmAllenkeytorotatethescrewclockwiseuntilthemotorbrakeis
released.
gTurnthecrankuntilthetransducerisfullylowered.
7Hoistingthetransducer
aTurnthecrankuntilthetransducerisfullyretracted.
bLoosenthebrakereleasescrewtoengagethemotorbrake.
cCheckwiththehandcranktoensurethatthemotorbrakeisengaged.
dRemovethehandcrankfromthestubshaft,andmountitinitsstorageposition
intheMotorControlUnit.
eActivatetheMotorProtectingSwitch(S301)bypressingtheoperatinghandleto
ON.
8MakesurethattheHoist/LowerSwitchissettoREMOTE.
Note
FornormaloperationfromtheOperatingPanel,theswitchmustbesettoREMOTE.
9Closethecabinetdoor.
10Insertthemainsfusesforthehullunit.
Relatedtopics
Loweringandhoistingthetransducerfromthesonarroom,page112
SimradSU90OperatorManual
