381291/C

125

Neithertoolsnorinstrumentsarerequired.

Context

Note

TheinputfromaspeedlogisessentialforSU90operation.Withoutspeedinformation,

theSU90willneitherbeabletopresentcorrectnavigationalinformation,nor

compensateforvesselmovements.ThislackofcompensationwillpreventtheSU90

fromprovidingcorrectechoinformation.

TheSensorInstallationpageallowsyourSU90tocommunicatewithexternalsensors

andsystems.Youmustspecifywhichcommunicationporttouse(LAN(LocalArea

Network)orserialport).Youcantypeacustomnametoidentifythesensorimport.In

thelistofvaliddatagramformats,selecttheformat(s)tobeacceptedbytheSU90.

Note

JustmakingchangesandselectingOKatthebottomofthepagewillnotinstallanything.

Selectwhattoinstall,denetherelevantparameters,andthenselectAdd.

Procedure

1ConnectthespeedlogtoanavailablecommunicationportonyourProcessorUnit.

ThisisdescribedintheSU90Installationmanual.

2OpentheSetupmenu.

3OntheSetupmenu,selectInstallation.

ObservethattheInstallationdialogboxopens.Thisdialogboxcontainsanumber

ofpagesselectedfromthemenuontheleftside.

4OntheleftsideoftheInstallationdialogbox,selectSensorInstallation.

5ForSensorType,selectSpeedLogtoimportinformationfromaglobalpositioning

system.

6Selectwhichportyouwanttoimportthesensorinformationon.

7Ifyouwanttocheckthecommunicationparameters,selectInspectPort.

Note

Youcannotmakeanychangeshere.Tochangethecommunicationparameters,

usetheI/OSetuppage.

Operatingprocedures
