381291/C

Procedure

1Clickintheviewyouwanttoactivate.

Theactiveviewisidentiedwithathickerborder.UnlessyouusetheApplytoall

function,allchangesyoumakewillonlybeappliedtothisview.

2Turntherelevantrotaryswitchtomaketheadjustment.

Tip

TheOperatingPanelisttedwiththreerotaryswitches.Theswitchesareidentied

withnumbers.Eachswitchcanbeassignedafunctionrelatedtorange,gainor

bearing.InvestigatethefunctionalityprovidedontheOperatingPanelpage.This

pageislocatedintheInstallationdialogbox.

Optionally:

3InaHorizontalview,selectthebearinglineanddragitsideways.

Optionally:

4ObservetheMainmenu.

ItsdefaultlocationisontherightsideoftheSU90presentation.

5SelectBearing.

6Makethenecessaryadjustment.

Select[+]or[-]tochoosetherequestedsetting.

or:

Placethecursoronthebutton.Pressandholdtheleft

mousebutton.Movethe

cursorhorizontallyoverthebutton.Releasethemousebuttonwhenrequested

valueisshown.

or:

Selectthemiddleofthebuttontoopenit.Ifyouhaveakeyboardconnectedtothe

SU90,youcantypetherequestedvalue.

7OpenthebuttonandselectApplytoallifyouwishtousethechosensettinginall

theviewsinthecurrentpresentationmode.

Relatedtopics

Startingnormaloperation,page20
