Context

UsetheinformationintheCatchviewtomonitortheprogressofthepurseseine

operation.IfyouhaveconnectedacompatiblecatchmonitoringsystemtoyourSU90,

informationfromthesesensorsareshownintheCatchview.

Procedure

1AtthebottomoftheSU90presentation,selectasuitable

presentationmode,andactivatetheCatchview.

2Tostarttheprocess:PressGearontheOperatingPanel.

or:

Right-clickandselectShowGearSymbolontheshortcutmenu.

Thisplacesacirclemarkerintheview.Thesizeandlocationofthemarkeris

denedbythechoicesyouhavemadewiththeFishingGearfunction.Untilyou

proceed,themarkerfollowsthemovementsofthevesselbykeepingitsrelative

locationtothebow.Thisallowsyoutopositionyourvesselinthebestpossible

locationbeforeyoushootthepurseseine.

3Whenyoushootthenet:PressGearontheOperatingPanel.

or:

Right-clickandselectShowGearSymbolontheshortcutmenu.

Arectangularmarkerisplacedintheview,andmarksthepositionwherethepurse

seinewasshot.Thecircularmarkerisdisconnectedfromthevesselmovements,and

actsasaguidelineforyourmanoeuvring.Thehistorylineshowsthemovementsof

yourvessel.SincetheSU90knowsthelengthofyournet,itplacesasecondmarker

onthislinewhenhalfthelengthhasbeenspent.Whentheentirenethasbeen

spent,athirdrectangularmarkerisshown.

TheprogressbaratthetopoftheCatchviewshowsyoutheamountofnetthathas

beenspent.Thesequencestartswhenyoushootthenet.Theestimateddepthofthe

purseseineisshownundertheprogressbar.Thedepthiscalculatedfromthesink

rateyouhavedenedfortheshinggear.

•Horizontaldottedlinesshowthedepthintervals.

•Relevantinformationaboutapriorityobjectcanbefoundinthelowerleftcorner

oftheview.

AlineofX’esintheverticalviewsshowsthebottomofthepurseseine.Thedepth

isdenedfortheshinggearyouhavechosen.

4Whentheprocessisnalized:PressGearontheOperatingPanel.

or:

Right-clickandselectRemoveGearSymbolontheshortcutmenutodeletethe

markersfromtheview.
