© Jun 2022 6-10 TB24 Plus&26J Plus Maintenance Manual
REPAIR PROCEDURES
NO. PART NUMBER DESCRIPTION QTY
34 18125706 Circlip for Shaft 1
35 79916216 Sun Gear 1
36 79913030 Retaining Ring 1
37 79911274 Planet Carrier 1
38 79917003 Ball Head 3
39 79916314 Planet Gear 3
40 18121067 Cylindrical Roller Bearing 3
41 18125718 Circlip for Shaft 3
42 18125717 Circlip for Shaft 1
43 11218010 Pressure Sring 1
44 79921012 Spline Assembly 1
45 79916315 Sun Gear 1
46 18125586 O-ring 2
47 79912187 Inner Gear Cover 1
48 18112003 Socket Head Plug 2
49 18112064 Socket Cap Screw 12
50 18125333 Framework Oil Seal 1
51 18125419 Circlip for hole 1
52 18125603 O-ring 1
53 79912188 End Cap, Small 1
54 18112047 Socket Cap Screw 2
Removal of reducer and drive motor
1. Place the machine on a solid, level surface.
2. Place a jack of sufficient capacity under the side of
chassis to be removed. Lift the jack to make the
wheel off the ground.
3. Remove the bolts and washers securing the wheel
to the reducer. Use a suitable lifting device to
remove the wheel.
4. Tag, disconnect and plug the hyrdaulic hoses to the
drive motor.
5. Remove the mounting bolts from drive motor, and
remove the drive motor.
6. Use a suitable lifting device to support the drive
reducer.
7. Remove the bolts and washers securing the drive
reducer to the outrigger, and remove the drive
reducer.
Installation of reducer and drive motor
1. Use a lifting device with sufficient capacity to
support the outrigger.
2. Align the reducer brake oil port with the nick of
support.
3. Fit the washer with the mounting surface, apply
threadlocker Loctite 272 to the bolts,and intall in
turns.
4. Tighten the bolts with a torque wrench.
5. After all installed, add a suitable level of gear oil.
6. Mesh the spline of motor with the inner gear of
reducer, slowly rotate the motor housing until the oil
port of motor faces outside and the motor mounting
slot is aligned with the reducer mounting bolt.
7. Apply the threadlocker Loctite 272 to the bolts and
torque the bolts after pretightening.
8. Attach the hrdraulic hoses.
