REPAIR PROCEDURES
TB24 Plus&26J Plus Maintenance Manual 6-9 © Jun 2022
Table 6-2
NO. PART NUMBER DESCRIPTION QTY
1 18112069 Socket Cap Screw 6
2 79913245 Coupling 1
3 18125605 O-ring 1
4 18125523 O-ring 1
5 11218001 Spring, Small 20
6 79913191 Spring Pocket 1
7 79913190 Piston 1
8 18125327 Glyd Ring for Shaft 1
9 18125111 Glyd Ring for Shaft 1
10 11219104 Static Friction Disc 6
11 11219103 Dynamic Friction Disc 5
12 18125443 Wire Snap Ring for Hole 1
13 79914192 Input Spline Assembly 1
14 18121107 Deep Groove Ball Bearing 1
15 18125716 Circlip for shaft 1
16 79912270 Brake Housing 1
17 79916013 Planet Gear 4
18 18121013 Cylindrical Roller Bearing 4
19 18125710 Circlip for Shaft 4
20 18125303 Floating Seal 1
21 79911015 Bearing Seat 1
22 18111020 Anti-spin Bolt 10
23 18111019 Socket Head Bolt 4
24 18121012 Cylindrical Roller Bearing 2
25 79913011 Locknut 1
26 79911183 Bearing Support 1
27 18125437 Circlip for Hole 1
28 79912186 Inner Gear Ring 1
29 79916156 Sun Gear 1
30 79911093 Planet Carrier 1
31 79916119 Planet Gear 3
32 18121066 Cylindrical Roller Bearing 3
33 18125703 Circlip for Shaft 3
