HRX-MM-N007
Chapter 4 Service Procedure
4.5 Replacement Procedure HRS Series
2. Mount the pump. (Screw ×4)
3. Mount the hose. (2 pcs.)
Tightening torque of hose between high pressure pump and circulating fluid outlet：
4. Connect the ground cable (G4). (Screw ×1)
5. Mount cable to the condenser.
6. Mount pump cable to the power board.
For the HRS030, fix the pump cable on the fan motor bracket with a cable tie to prevent
the pump cable from touching the fan.
7. Mount the support panel. (Screw ×2)
8. Mount the upper panel and the right panel in reversed order of removal.
