User Manual |
123
Laser Engraving and Cutting - 05 Maintenance
• Into the Converters
• On the Laser Module
5.2.2 Check the Support Platform
Check if the Support Platform is assembled in the correct direction. The front without screws should face up, and the
rear with some screws faces down. The reversely installed platform will be higher than the correctly installed one.
Z Cables
Y Cables
Converters
