Snom C520 - Install the Wireless MIC Battery

3 4
Geng Started
To power the C520 using PoE:
1. Plug one end of the Ethernet cable into the Ethernet port on the boom of the unit.
2. Plug the other end of the cable into your network router or switch. When the base
unit is powered up, the status indicators turn green for about two seconds.
Note: You can connect the C520 to both PoE and AC power. Ensure that you
connect the cables in the order shown in the diagram on page 3. The phone
will use PoE; if PoE fails, the phone will use AC power as a backup.
Install the wireless mic baery
1. Plug the baery connector securely into the socket inside the baery
compartment. Insert the baery (with the label THIS SIDE UP facing up) into the
baery compartment.
2. Slide the baery door unl it clicks into place.
3. Place the wireless mic onto the charging cradle.
Note: The status indicator on the wireless mic turns orange when charging, and
turns o when the wireless mic is fully charged.
