Sonic 2024 User Manual

Example of UDP/IP Ethernet packet of commands sent to the sonar head.
First 42 characters are Ethernet header information. Characters after 29h are commands
0000 00 50 c2 90 43 3d 00 e0 81 2e be 88 08 00 45 00 .P..C=........E.
0010 01 40 7b 73 40 00 80 11 00 00 0a 00 01 66 0a 00 .@{s@........f..
0020 00 56 06 a1 ff de 01 2c df c3 43 4d 44 30 41 42 .V.....,..CMD0AB
0030 53 30 42 a0 00 00 53 50 52 30 41 f0 00 00 53 56 S0B...SPR0A...SV
0040 4c 30 44 bb 80 00 53 56 55 30 00 00 00 00 52 47 L0D...SVU0....RG
0050 4f 30 00 00 00 00 41 55 54 30 00 00 00 00 52 4e O0....AUT0....RN
0060 47 30 41 a0 00 00 47 41 4e 30 41 50 00 00 46 52 G0A...GAN0AP..FR
0070 51 30 48 c3 50 00 54 58 50 30 43 3f 00 00 54 58 Q0H.P.TXP0C?..TX
0080 4c 30 37 a7 c5 ac 53 45 57 30 40 06 0a 92 44 47 L07...SEW0@...DG
0090 41 30 40 a8 f3 12 44 47 42 30 41 0c ca 8f 44 47 A0@...DGB0A...DG
00a0 53 30 00 00 00 00 44 47 4f 30 00 00 00 01 50 52 S0....DGO0....PR
00b0 4c 30 3f 80 00 00 50 52 55 30 00 00 00 00 52 45 L0?...PRU0....RE
00c0 54 30 00 00 00 00 50 52 4f 30 00 00 00 00 50 52 T0....PRO0....PR
00d0 5a 30 3d f3 b6 46 53 45 52 30 00 00 00 00 42 4f Z0=..FSER0....BO
00e0 53 30 00 00 00 00 54 57 49 58 00 00 00 00 50 52 S0....TWIX....PR
00f0 4f 4a 00 00 00 01 52 4f 53 30 00 00 00 01 44 48 OJ....ROS0....DH
0100 4d 30 00 00 00 00 53 4e 49 50 00 00 00 00 42 49 M0....SNIP....BI
0110 45 30 00 00 00 00 41 49 48 30 00 00 00 00 41 49 E0....AIH0....AI
0120 42 30 40 c0 00 00 57 43 4d 30 00 00 00 00 54 50 B0@...WCM0....TP
0130 4d 30 00 00 00 00 54 50 47 30 00 00 00 00 54 52 M0....TPG0....TR
0140 47 30 00 00 00 00 53 54 4d 30 00 00 00 02 G0....STM0....
Example of UDP/IP Ethernet packet of commands sent to the SIM.
First 42 characters are Ethernet header information. Characters after 29h are
commands.
0000 00 50 c2 90 41 35 00 e0 81 2e be 88 08 00 45 00 .P..A5........E.
0010 01 18 7b 74 40 00 80 11 00 00 0a 00 01 66 0a 00 ..{t@........f..
0020 00 63 06 a2 ff de 01 04 fa f0 43 4d 44 30 45 4e .c........CMD0EN
0030 47 30 00 00 00 01 42 44 47 30 00 00 25 80 44 42 G0....BDG0..%.DB
0040 47 30 00 00 00 08 44 52 47 30 00 00 00 00 50 41 G0....DRG0....PA
0050 47 30 00 00 00 00 53 42 47 30 00 00 00 01 50 4f G0....SBG0....PO
0060 47 30 00 00 00 01 53 59 49 30 00 00 00 00 53 59 G0....SYI0....SY
0070 4f 30 00 00 00 00 45 4e 48 30 00 00 00 01 42 44 O0....ENH0....BD
0080 48 30 00 00 25 80 44 42 48 30 00 00 00 08 44 52 H0..%.DBH0....DR
0090 48 30 00 00 00 00 50 41 48 30 00 00 00 00 53 42 H0....PAH0....SB
00a0 48 30 00 00 00 01 45 4e 4d 30 00 00 00 01 49 50 H0....ENM0....IP
00b0 4d 30 0a 00 00 2f 50 4f 4d 30 00 00 13 88 42 44 M0.../POM0....BD
00c0 4d 30 00 00 96 00 44 42 4d 30 00 00 00 08 44 52 M0....DBM0....DR
00d0 4d 30 00 00 00 00 50 41 4d 30 00 00 00 00 53 42 M0....PAM0....SB
00e0 4d 30 00 00 00 01 45 4e 53 30 00 00 00 01 42 44 M0....ENS0....BD
00f0 53 30 00 00 25 80 44 42 53 30 00 00 00 08 44 52 S0..%.DBS0....DR
0100 53 30 00 00 00 00 50 41 53 30 00 00 00 00 53 42 S0....PAS0....SB
0110 53 30 00 00 00 01 53 50 4f 30 00 00 00 01 53 54 S0....SPO0....ST
0120 4d 30 00 00 00 02 M0....
Page 174 of 210
Version 5.0 Rev r002
Date 05-08-2014
Part No. 96000001
