Sonic 2024 User Manual

2.4 Sonic 2022 Dimensions and Weights
Component
Dimensions (L x W x D) / Dry Weight
Receiver Module
276mm x 109mm x 190mm / 7.7kg
Projector
273mm x 108mm x 86mm / 3.3kg
Sonar Interface Module (SIM)
280mm x 170mm x 60mm / 2.4kg
I2NS Sonar Interface Module (SIM)
280mm x 170mm x 126.4mm / 4.2kg
Receive module and Projector mass in water
4.0kg (Fresh)
2.5 Sonic 2024/Sonic 2022 Electrical Interface
Item
Specification
Mains Power
90 – 260 VAC; 45 – 65 Hz
Power Consumption (SIM and Sonar Head)
75 Watt (Sonic 2022: 54 Watt)
Power Consumption (Sonar Head Only)
50W avg.; 90W Peak (Sonic 2022: 35W avg.; 70W
Peak)
Integrated Inertial Navigation System (I2NS)
38.4W (SIM and IMU with Antennas)
Uplink/Downlink
10/100/1000Base-T Ethernet
Data Interface
10/100/1000Base-T Ethernet
Sync IN/OUT
TTL
GPS Timing
1PPS; RS232 NMEA
Auxiliary Sensors
RS232 / Ethernet
Deck Cable Length
15 metre (optional to 50 metres)
Table 4: Electrical Interface
2.6 Sonic 2024/2022 Ping Rates (SV = 1500.00m/sec)
RANGE
PING RATE
2 - 7
60.0
10
55.4
15
39.4
20
30.6
25
25.0
30
21.1
35
18.3
40
16.1
50
13.0
70
9.4
100
6.7
150
4.5
200
3.4
250
2.7
300
2.3
400
1.7
450
1.5
500
1.4
700
1.0
1000
0.7
1200
0.6
Table 5: Ping Rate table
WARNING
THE RECEIVE MODULE IS FILLED WITH
OIL THAT WILL FREEZE TO A SOLID AT
-10°C. STORAGE BELOW THIS
TEMPERATURE (TO -30°C) IS POSSIBLE IF
THE HEAD IS SLOWLY THAWED OUT
PRIOR TO OPERATION.
Page 22 of 210
Version 5.0 Rev r002
Date 05-08-2014
Part No. 96000001
