5.10 Help
Figure 75: The Help Menu
5.10.1 Help Topics
Selecting Help Topics will bring up an electronic copy of the Operation Manual. This is the same as
the paper version of the Operation Manual.
5.10.2 Options
The Options display shows the upgrades that have been installed in the system. The installed
options are enabled or disabled, as required, in the Sonar Settings (except for the 3000m depth
rating upgrade); this display merely shows what is available for the system. Enabling an installed
option’s output is done in Sonar Settings.
Figure 76: Installed Options
5.10.3 Remote Assistance
R2Sonic support can assist in setting up the system or trouble shooting the system, remotely, by
taking control of the customer’s computer. An internet connection is required.
Figure 77: Remote Assistance
Page 73 of 210
Version 5.0 Rev r002
Date 05-08-2014
