2 SONIC SPECIFICATIONS
2.1 Sonic 2024 System Specification
System Feature
Specification
Frequency
400kHz / 200kHz
Beamwidth – Across Track (at nadir)
0.5°@ 400kHz / 1.0° @ 200kHz
Beamwidth – Along Track (at nadir)
1.0° @ 400kHz / 2.0° @ 200kHz
UHR Beamwidth (at nadir)
0.3° Across Track x 0.6° Along Track
Number of Beams
256
Swath Sector
10° to 160° (user selectable)
UHR Swath Sector
10° to 60° (user selectable)
Maximum Slant Range
1200 metres
Pulse Length
15µSec – 1000µSec
Pulse Type
Shaped Continuous Wave (CW)
Depth Rating
100 metres (3000 metres optional)
Operating Temperature
-10° C to 40° C
Storage Temperature
-30° C to 55° C
Table 2: System Specification
2.2 Sonic 2022 System Specification
System Feature
Specification
Frequency
400kHz / 200kHz
Beamwidth – Across Track (at nadir)
1.0°@ 400kHz / 2.0° @ 200kHz
Beamwidth – Along Track (at nadir)
1.0° @ 400kHz / 2.0° @ 200kHz
UHR Beamwidth (at nadir)
0.6° Across Track x 0.6° Along Track
Number of Beams
256
Swath Sector
10° to 160° (user selectable)
UHR Swath Sector
10° to 60° (user selectable)
Maximum Slant Range
1200 metres
Pulse Length
15µSec – 1000µSec
Pulse Type
Shaped Continuous Wave (CW)
Depth Rating
100 metres (3000 metres optional)
Operating Temperature
-10° C to 40° C
Storage Temperature
-30° C to 55° C
2.3 Sonic 2024 Dimensions and Weights
Component
Dimensions (L x W x D) / Dry Weight
Receiver Module
480mm x 109mm x 190mm / 12.9kg
Projector
273mm x 108mm x 86mm / 3.3kg
Sonar Interface Module (SIM)
280mm x 170mm x 60mm / 2.4kg
I2NS Sonar Interface Module (SIM)
280mm x 170mm x 126.4mm / 4.2kg
Receive module and Projector mass in water
5.9kg (Fresh)
Table 3: Component Dimensions and Mass
