Throttle Curve
Adjusting the Normal Throttle Curve
Adjustment of the throttle curves is similar to the pitch curve adjustment described on the preceding page. Three
throttle curves are available: normal, stunt 1 and stunt 2. All throttle curves have five adjustable points—low,
25%, 50%, 75% and high. Flight modes are located on the 3-position flight mode switch. The throttle curve is
in the normal mode when the Flight Mode switch is in the rear position and the Throttle Hold switch is rearward.
To Access the Throttle Curve Function
Turn the power on and press the DowN and SELECT keys simultaneously to enter the function mode.
Press the UP or DowN key until THROTTLE CURVE NORM appears on screen.
Press the SELECT key to select the stick position that you wish to adjust the throttle.
• L= Low
• 1= 25%
• 2= 50%
• 3= 75%
• H= High
Press the INCREASE or DECREASE keys to adjust the throttle value of the selected throttle position.
Note: For more information about setting up Throttle Curves see Page 87.
This completes the basic Quick Start setup for your helicopter. For additional features like Dual and Expo Rates,
Mixing, etc, see the appropriate pages listed in the table of contents.
