71SPEKTRUM DX7 • HELICOPTER PROGRAMMING GUIDE
Trainer
The DX7 offers a programmable Trainer function that allows the transmitter to operate in three different
Trainer modes. The left or right rocker can be programmed as the trainer switch.
NORMAL:
The transmitter can be used as a master or slave, but the slave transmitter must have the same programming (i.e.
reverse, travel adjust, dual rates, mixes sub trims, etc.) as the master.
P-LINK:
In Pilot Link the master transmitter maintains control of all secondary functions (i.e. dual rate, expo, gear,
flaps, etc.) and only the primary stick controls (aileron, elevator, rudder and throttle) are transferred to the slave
transmitter when the trainer switch is pressed.
SLAVE/P-LINK:
In the Slave mode, the DX7 is used as a slave radio in conjunction with a Spektrum
®
radio that is used as the
master that is in P-LINK mode; there is no need to match the slave’s programming to the master transmitter’s
programming in this mode.
[TRAINER]
≥NORMAL
SW:L-ROCKER
Press to select trainer type
Press to enter
TRAINER FUNCTION
Hold while turning on transmitter
To Enter the Trainer Mode
Press the DowN and SELECT keys simultaneously, then turn on the transmitter.
Press the UP key until TRAINER function appears on screen.
Press the INCREASE or DECREASE key to select the desired Trainer type: INH, Normal, P-Link or
Slave/P-Link. Also note that the trainer switch can be located on the right or left rocker switch. Use the
select key to highlight SW:R then press the increase or decrease key to select the right (R) or left (L) rocker.
