52 SPEKTRUM DX7 • AIRCRAFT PROGRAMMING GUIDE
Aileron-to-Rudder Mixing
The Aileron-to-Rudder Mixing function is designed so that when input to the aileron stick is given, the rudder
servo will also move, eliminating the need to coordinate these controls manually. This mixing program can
be turned ON/OFF by a switch. The switches that can be selected are shown below, with their abbreviations as
they appear on the screen and the corresponding switch positions. Mix values are adjustable from 0 to 125%.
When adjusting the mix value, if an opposite mixing direction of the rudder servo is required, simply press the
INCREASE or DECREASE key and change the mixing value from + to - or - to +. This will reverse the mixing
direction of the rudder from its original direction.
• ON: Mixing Always ON
• MIX Switch ON/OFF Using Mixing Switch
• Flap 0 Switch ON/OFF Using Flap Mix Position 0
• Flap 2 Switch ON/OFF Using Flap Mix Position 2
[AILE->RUDD MIX]
◊RATE: 0%
OFF
SW: MIX
Press to adjust value
Press to enter
AILE-RUDD MIX
Press to enter
Function Mode
Press to return
value to default
Press to highlight
RATE or SW
To Access the Aileron-to-Rudder Mix Function
Press the DowN and SELECT keys simultaneously to access the Function Mode.
In Function Mode, use the UP or DowN key to select the AILE-RUDD MIX screen.
Press the SELECT key to highlight RATE or SW (switch).
To Adjust the Mix Value
With RATE highlighted, press the INCREASE or DECREASE keys to adjust the mix value.
Note: To reverse mix directions, a negative mix value is accessible.
To Assign a Switch
With SW highlighted, press the INCREASE or DECREASE keys to select the desired switch used to turn on/off
the mix (Flap 0 or Mix).
