53SPEKTRUM DX7 • AIRCRAFT PROGRAMMING GUIDE
Flap System
The purpose of the Flap System is to set the flap and elevator positions for landing and takeoff. This is
accomplished by selecting values for the elevator and flaps to be activated when the Land Switch is engaged.
Three flap and elevator positions are available. The landing system can also be activated by a preset position
of the throttle stick. Refer to the Automatic Landing Attitude section for more information on how to select the
preset throttle position.
Note: The Flap System is only operational when SYSTEM is selected under Flap in the Input
Select screen. See page 41 for more detail.
[FLAP SYS.] NORM
FLAP ELEV
NORM ◊UP100% 0
0
0
MID
LAND
AUTO INH
DN100%
0%
Press to adjust value
Press to enter FLAP SYSTEM
Press to enter
Function Mode
Press to return
value to default
Press to highlight
the desired function
Accessing and Utilizing the Flap System
Press the UP and SELECT keys simultaneously to enter the Function Mode.
Press either the UP or DowN keys until FLAP SYS appears in the upper left portion of the LCD.
Press the SELECT key to position the cursor at the desired function (i.e., ELEV, FLAP, SPOI, AUTO).
Note: The flap system can only be accessed when SYSTEM is selected in the Input Select
screen under flaps. See page 41 for more details.
Press the UP or DowN keys to set the value for flap and elevator travel. The UP key adds up flap/elevator and
the DowN key adds down flap/elevator. The input is adjustable from 125% for flap and -200% for elevator.
