Spektrum DX7 User Guide

73SPEKTRUM DX7 • HELICOPTER PROGRAMMING GUIDE
Input Select
The Input Select function is used to select the switch input for the gyro gain and the channel that will operate
the gyro gain.
[INPUT SELECT]
≥AUX2 GEAR
GYRO INH
INCREASE and DECREASE key
Press to enter
INPUT SELECT
Hold while turning on transmitter
To Select the Function for the AUX2 Channel
Press the DowN and SELECT keys simultaneously, then turn on the transmitter.
Press the UP or DowN key until the INPUT SELECT function appears on screen.
Press the SELECT key until AUX2 is highlighted.
Press the INCREASE or DECREASE key to select the desired function.
The Auxiliary 2 channel options are:
INH:
Inhibit is selected if the gyro function will not be used on the Aux 2 channel.
F.MODE:
In this mode, the AUX2 channel is controlled by the flight mode switch and three positions are available. Sub
trim and travel adjust is used to set the center and end points for each switch position.
AUX2:
The Auxiliary 2 switch controls the AUX2 Channel.
GYRO:
The gyro mode is selected if you want to use the Gyro Sensing (see page 91) for more detail. Selecting GYRO
under AUX2 assigns the gyro sensing program to operate use the AUX2 channel. In this case the gyro gain must
be plugged into the AUX2 (Channel 7) channel.

Spektrum DX7 Specifications

General

Interface	RF Wireless
Product color	Black
Remote control proper use	-
Built-in display	Yes
Maximum range	- m
Frequency band	2.4 GHz
Channels quantity	7 channels
Number of devices supported	250
Battery capacity	2000 mAh
Quantity per pack	1 pc(s)

Weight and Dimensions

Weight	- g
