91SPEKTRUM DX7 • HELICOPTER PROGRAMMING GUIDE
Gyro Sensing
The DX7 offers two different types of Gyro Sensitivity Adjustments — manual or automatic. This feature gives
the user the choice of selecting gyro sensitivity manually through the rudder dual rate switch or automatically
through the flight mode switch.
[GYRO SENS]
◊AUTO F.MODE
RATE:
0: 50%
1: 50%
NORM:0
STNT:0
Press to enter
GYRO SENS
Press to enter
Function Mode
Press to return
value to default
Press to select
desired function
To Access the Gyro Sensing Function
In function mode, press the UP or DowN key until GYRO SENS screen appears on the screen.
Use the SELECT key to highlight the desired RATE or FLIGHT MODE.
Press the INCREASE or DECREASE key to change the rate value or the select position 0 or 1 for
each flight mode.
Note: In order to access the Gyro Sensing function, it is necessary to select Gyro in the Input
Select screen and assign it to AUX2 or the gear channel. See Page 73 for more details.
Manual Gyro Sensitivity Adjustment
Manual Gyro Sensitivity Adjustment allows the pilot to select from two different gyro sensitivities during all flight
conditions. This function is activated in conjunction with the rudder dual rate switch.
Automatic Gyro Sensitivity Adjustment
The Automatic Gyro Sensitivity Adjustment feature allows the pilot to automatically alter the sensitivity of
the gyro from either of two pre-determined settings through the use of the flight mode switch. As different
flight modes are selected (Normal, 1, 2, Hold), the Gyro’s sensitivity rate will switch to the pre-determined
compensation rate for each particular flight mode in use.

Spektrum DX7 Specifications

General

Interface	RF Wireless
Product color	Black
Remote control proper use	-
Built-in display	Yes
Maximum range	- m
Frequency band	2.4 GHz
Channels quantity	7 channels
Number of devices supported	250
Battery capacity	2000 mAh
Quantity per pack	1 pc(s)

Weight and Dimensions

Weight	- g
