Hydraulic function Explanation
LS Load Sensing, always
with T and P
Load Sensing is recommended so that the oil only ows when it is needed.
For Load Sensing, the ball valve above the oil tank must be closed (set at
right angles to the line).
DA Double acting control
unit
For DA and SA, the ball valve must
be open (see arrow in the image
on the right).
SA Single acting control unit
P Flow of oil from the
pump
T Flow of oil to the tank
