Sliding parts screwed into tool holders on the arm of a nger
weeder
Sliding parts screwed into tool holders on a Combi-Element
Sliding part on a Basic-Element
The outer tools are screwed onto sliding parts. Depending on the
variant, the user can move the tools on the sliding parts or the sliding
parts themselves in the tool holders in transverse direction. This allows
the user to adjust the working width of the tools or compensate for
small deviations in the row distance.
To move tools:
1. Undo the screw connection.
2. Move the sliding part or tools on the sliding parts.
ð
The tool widths correspond to the widths of the strips of soil
to be cultivated.
3. Tighten the screws.
Move tools on the sliding parts
Operation
en-GB | Item no. 17513597 | BA 02/05-2022 75
