6.3.5.1 Basic operation
The tools are attached as follows:
n Knives, weeders, harrows, protection discs and ridgers on the Basic-
Element, Combi-Element or TRS-Element
n Finger weeders on spring-loaded arm
The tool legs are screwed into the sliding parts with hexagon bolts. The
sliding parts are either screwed directly to the hoeing element or into
tool holders.
3
4 1
2
1
Sliding parts for tools on the hoeing element
2
Screw fastening of the tool
3
Sliding parts on the double spring arm
4
Tool holders on the double spring arm
To replace a tool:
1. Undo the screw(s).
2. Remove the tool from the xing element.
3. Slide the new tool onto the xing element.
4. Tighten the screw(s).
INFORMATION
Store unused tools in a dry place.
Tool attachment
Loosen and tighten tools
Operation
en-GB | Item no. 17513597 | BA 02/05-2022 77
