Position / Button Meaning
5 ‘Minimum Speed Limit [x] km/u’ : Enter minimum speed in km/h for receiving GPS signals.
This may be helpful if the GPS signals are weak. The lower the speed, the stronger and
more constant GPS signals need to be. A guidance value for the minimum speed is
3 km/h. If the speed falls below the speed set here, the “AUTO” button in the main menu
is yellow. The colour warns of missing GPS signals.
6 Dead band value for pressure: 2...10 kg. The dead band value denes the tolerance
between the set pressure and the actual pressure. The actual pressure uctuates con‐
tinuously during operation. The dead band value prevents the hydraulic system from
constantly trying to reach the set pressure (either by sending more oil into the hydraulic
system or by sending oil out of the system to the tractor).
If the hydraulics react in this way too often, the dead band value is set too low and must
be increased.
7 Software version
8 Display of the current pressure
The pressure uctuates during operation.
9 ‘Pressure Control’ : Pressure Control
When the function is activated, the user can enter a value for the pressure with which
the hoeing elements are pressed into the ground.
Precondition: The ram on the hoeing element is equipped for this purpose.
10 ‘Hitch Control’ : Control by the hydraulics of the tractor machine combination
When both the function and the GPS automatic function are activated, the GPS auto‐
matic function button turns red when the hoeing machine is lifted.
Section Control no longer responds to GPS signals.
There are three settings for the behaviour of the elements on a lifted machine:
n All elements remain in the last position.
n All elements are lowered.
n All elements are lifted.
11 Buttons:
Open the Machine conguration menu.
Open the main menu.
Operation
en-GB | Item no. 17513597 | BA 02/05-2022 88
