Position / Button Meaning
Enter the pressure for lowering (see also main menu).
Enter the dead band value for pressure.
Recommended value: Between 2 and 10 kg. The more the actual pressure at the set
pressure uctuates, the higher the setting of the dead band value needs to be.
Open the ‘Section Control Timing’ menu.
1
2
3
4
5
7
8
6
‘Machine layout’ menu: Machine conguration
1
2
3
4
5
6
7
8
Position / Button Meaning
1
‘Rear Oset Boom’ : Rear frame oset (overlap tolerance)
Distance between the GPS antenna on the tractor and the point on the hoeing element
where the hoeing element is lifted while driving.
Refer to the tractor documentation to determine the exact position of the GPS antenna.
2
‘Right Oset Boom’ : Row oset to the right
For double hitch frame: If the frame is mounted laterally oset, enter a value here.
‘Machine conguration’ menu
Operation
en-GB | Item no. 17513597 | BA 02/05-2022 89
