4-6
920509-645 Operator Manual Operating Instructions
If water saver is enabled, sump water is sent back to acid tank
(if option applies).
If sump flush option is available, water still present in sump is
gravity-drained.
If sump flush option is available, water is injected in sump to
remove debris.
If sump flush option is available, refreshed water still present
in sump is gravity-drained.
• RINSE 1 PHASE
Hot water, from building supply, fills sump.
Rinse 1 water is recirculated through oscillating jet system for
programmed amount of time.
Printer records time and solution temperature in chamber sump
at beginning and end of recirculation.
Water still present in sump is gravity-drained (option).
• RINSE 2 PHASE
Hot water, from building supply, fills sump.
Rinse 2 solution is recirculated through oscillating jet system for
programmed amount of time.
Printer records time and solution temperature in chamber sump
at beginning and end of recirculation.
Sump water is pumped to drain.
Water still present in sump is gravity-drained (option).
• FINAL RINSE PHASE
Hot water, from building supply, fills sump.
Final Rinse solution is recirculated through oscillating jet system
for programmed amount of time.
Printer records time and solution temperature in chamber sump
at beginning and end of recirculation.
Water contained in traveling spray header is sent to sump.
Sump water is pumped to drain.
Water still present in sump is gravity-drained (option).
• EXHAUST PHASE
Washer stands idle for programmed time interval allowing
residual vapors to exhaust from wash chamber to room.
Printer records time at the beginning and at completion of
phase.
NOTE: Customer must connect exhaust vent to building exhaust
system to prevent directly exhausting vapors to room.
• CYCLE COMPLETE
Alarm buzzer sounds and CYCLE COMPLETE is displayed.
Alarm buzzer can be silenced by opening chamber door(s).
WARNING – BURN HAZARD:
When cycle is complete, par-
tially open chamber door and
allow chamber and load to
cool. Hot steam may escape
through door opening if door
is fully opened after a cycle.
