Still CX - Datasheet (VDI)

Technical characteristics 7
Datasheet (VDI)
Datasheet (VDI)
DESCRIPTION CX 20 CX-D 20
1.1
Manufacturer
–
STILL STILL
1.2
Model type
–
CX 20 CX-D 20
1.3 Power source
–
Electric Electric
1.4
Driving mode
–
Order picking Order picking
1.5
Nominal capacity/load
Q(kg)
2000 2000
1.6 Load centre
c (mm)
1200 600
1.8
Load front offset
x (mm)
1615 942
1.9 Wheelbase
y (mm)
2843
1
2308
WEIGHT CX 20 CX-D 20
2.1
Weight in running order (with battery) kg
1145 1380
2.2
Load per laden axle, drive side/load side kg
1250/1895 1256/2132
2.3
Load per unladen axle, drive side/load
side
kg
880/265 934/446
WHEELS CX 20 CX-D 20
3.1
Tyre material
–
Vulkollan®
Polyurethane
3.2
Wheel sizes, drive side
Øx
l [mm]
Ø 250 x 100 Ø 250 x 100
3.3
Wheel sizes, load side
Øx
l [mm]
Ø85x80 Ø85x61.5
3.4 Rollers
Øx
l [mm]
Ø 150 x 50 Ø 150 x 50
3.5
Number of wheels, drive side/load side
(x = drive wheel)
–
1x1/4 1x1/4
3.6
Track width, drive side
b10 [mm]
475 475
3.7
Track width, load side
b11 [mm]
348 380
DIMENSIONS CX 20 CX-D 20
4.2
h1 [mm]
–
1280
4.4 Lift
h3
(mm)
130 1580
4.8
Floor height
h7
(mm)
135 136
4.9
Tiller h
eight/steering wheel in driving
positio
n, min./max.
h14
(mm)
1165 1165
50
108043405 [EN] 141
