Still CX - CX-H Version

4 Overview
Controls and display elements
CX-H version
800 Kg
800 Kg
1800 mm
600 mm
600 mm
h3= 1580 mm
800 Kg
800 Kg
2259
1
2260
The capacity plate (1) indicates truck load
capacity in kg according to the centre-of-
gravity distance and lift height. If two loads
are transported at the same time, arrange the
loads as shown on the plate (1).
Forbidden!
It is strictly forbidden to use the
truckasado
uble stacker (2).
44
50108043405 [EN]
