Still CX User Manual

Technical characteristics 7
Wheels and tyres
MISCELLANEOUS CX 20 CX-D 20
8.1
Speed control –
AC controller AC controller
8.4
Noise level at operator’s ear dB (A)
66.5 73.3
1
With 600 Ah battery case: + 85 mm
2
Max. gradient limited by the geometry of the truck
.
Wheels and tyres
Approved types of tyres
Only the types of wheels indicated in this
manual can be used.
Fork dimensions
Values for turning radius Wa for working
aisle width calculation
NOTE
all values in mm
Battery tray
Forks length
Distance X
450 Ah 600 Ah
1190 1005 2430 2516
1450 1265 2690 2776
1650 1105 2530 2616
2150 1605 3030 3116
2390
a)
1845 3270 3356
2390
b)
1615 3040 3126
2900 2125 3550 3636
3100 2125 3550 3636
a)
Wheelbase suitable for picking up 3 Euro pallets CROSSWAYS
b)
Wheelbase suitable for picking up 2 Euro pallets LENGTHWAYS
.
50
108043405 [EN] 143
