1 Foreword
Information about documentation
1044_001-014
4
2
3
1
Definition of directions
The references forward (1), backward (3),
right (2) and left (4) when describing location
are made relative to the operator’s station.
The load is at the rear.
Sample graphics
This documentation explains the (usually
sequential) sequence of certain functions or
operations. Schematic diagrams of a truck are
used to illustrate these sequences.
NOTE
These schemat
ic diagrams are not represen-
tative of the c
onstructed state of the docu-
mented truck.
They serve only to illustrate the
sequences.
