Operation 5
Driving
Backwards driving
– Press the lower part of the drive switch with
your thumb.
– The speed of the fork lift truck
increases as
you push the traction switch fu
rther,uptoa
limit of 2,5 km/h.
– When the traction switch is released, the
fork lift truck brakes electrically.
Reversing direction of travel
– Cease current direction of travel.
– Operate the drive switch in
theoppositedi-
rection of travel until y
ou reach the required
speed.
1044_501-006
1
2
3
Driving, pedestrian op
eration with
push button
NOTE
The fork lift truck i
s fitted with push buttons
(1) and (2) on both si
des of the seat backrest,
enabling the truck t
obedriveninpedestrian
mode from either sid
e. The speed is reduced;
the tiller (3) can be
used at any time to steer so
that the truck keeps
goingforwardinastraight
line.
CAUTION
Take care when operating, especially if the user is
not familiar with using this function.
50
108043405 [EN] 71
