Objet260 User Guide 5 Using Objet Studio
DOC-37004 Rev.E 5-84
JobsQueue
Ontheserver,theJobs Queueliststhelast15jobssentfromclientcomputers.
Onclientworkstations,theJobs Queuelistsjobssentfromthatcomputertothe
printerserver.
Informationforeachofthequeuedjobsisdisplayed,includingthejobstatus.
Status Meaning
Waiting Printingofthisjobhasnotstarted.
Building Printingofthisjobisinprogress.
Stopped Printingofthisjobwasinterrupted.Printingcanlaterbecontinued
(Resume)orbegunagain(Restart).
Error Errorsoccurredduringtheprintingofthisjob,anditwasplacedin
theJobsQueueagain.
Editing
ThisjobisnowbeingeditedinObjetStudio.
Spooling Thejobfileisbeingspooledintheprinter.
Preprocessing
The3Dprinterisreadyingitselfforprinting:thecoverlocks,
printheadswarmupandareputinstartingposition,UV
lampsareturnedon,andthebuildtraylevelisadjusted.
OnSchedule Thejobisscheduledtobeprintedataspecifiedtime.
Inaddition,thefollowinginformationisdisplayed:
•Owner—thecomputerthatsentthejob
•Build Time—theestimatedbuildingtimeforthejob
•ModelConsumption—theamountofmodelmaterialrequiredtocomplete
thejob,andtheamountactuallyusedtillnow
•SupportConsumption—theamountofsupportmaterialrequiredto
completethejob,andtheamountactuallyusedtillnow
•Printing Mode—HS=HighSpeed,HQ=HighQuality,DM=DigitalMaterial
Printing
Progress
TheTimepanelshowsprintingtimesandthenumberofslicessenttothe
printer.
History
TheHistorypanelshowsinformationforthelast50jobsandtheirfinal
status.YoucandragajobfromHistorytoJobs Queuetoprintthetrayagain.
Available
Resources
TheAvailable Resourcespanelcontainsgraphicindicatorsthatshowthe
amountofavailableprintingmaterialsremainingintheprinter.
1
Material
Consumption
•Actual—theamountofmaterialusedtillnow
•Required—theamountofmaterialstillneededtofinishthejob
1
ObjetStudiodisplaystheweightoftheprintingmaterialsinbothcartridgesaslongaseachcartridgecontainsmorethan100gramsof
material.Theweightunder100gramsisnotcalculatedanddisplayed.However,ifacartridgecontainslessthan100gramsofmaterial,
theprinterusesit—aslongasthematerialintheothercartridgeweighsmorethan100grams.Inanycase,theweightofeachcartridge
isdisplayedintheprinterapplication.
