Objet260 User Guide 3 Introducing the Objet260 3D Printing System
DOC-37004 Rev.E 3-10
Objet Studio Software
TheObjetStudioprogramfortheObjet2603Dprintingsystemconsistsof
twomainscreens:
•TraySettings/ModelSettings
•JobManager
TraySettings/ModelSettings
IntheTray SettingsandModel Settingsscreens,youpreparesourcefilesfor
productioninObjet2603Dprinters.ObjetStudiooffersyouawidevarietyof
file-preparationoptions,butalwaysconsistsofthefollowingbasicprocedure:
1. Placingoneormoreobjectsonthebuild tray
2. Positioningtheobject(s)onthetray
3. Configuringobjectandtrayparameters
4. Savingthetrayconfigurationasanobjtf(trayformat)file
5. SendingtheobjtffiletotheObjet2603Dprinterforproduction
UsingObjetStudiotoperformthesetasksisdescribedindetailinChapter5,
"UsingObjetStudio".
JobManager
TheJob Managerscreenisdifferentforclientworkstationsandforthe
computerconnecteddirectlytotheObjet2603Dprinter.
•InObjetStudioinstalledonthedirectly-connectedcomputer(server),the
Job Managerscreendisplaysthequeueandstatusforalljobssenttothe
3Dprinterbytheserveritselfandbyallclientcomputersonthenetwork.
Alljobsdisplayedcanbeeditedandmanipulated.
•InObjetStudioinstalledonclientcomputers,theJobManagerscreen
displaysthequeueandstatusonlyforjobssenttoa3Dprinterserverfrom
thatcomputer.Onlythesejobscanbeeditedandmanipulatedfromthe
clientcomputer.
Clientcomputerscanbeconnected,viathelocalnetwork,toPolyJet3D
printers,butonlytooneatatime.TheJob Managerscreendisplaysthe
statusofthe3Dprintertowhichtheclientiscurrentlyconnected.
