Stratasys Objet260 - Using Objet Studio

DOC-37004 Rev.E 5-1
5
Using Objet Studio
LaunchingObjetStudio 5-4
Windows®7SecurityWarning 5-4
ObjetStudioInterface 5-6
RibbonCommands 5-8
ObjetStudioCommandsMenu 5-10
ModelTreePane 5-10
AssigningPropertiestoHiddenObjects 5-11
PreparingModelsforProduction 5-12
OBJDFFiles:Overview 5-12
ModelFiles 5-12
PlacingObjectsontheBuildTray 5-13
OpeningObjetTrayFiles 5-18
Quick-AccessModelCommands 5-20
SelectingObjects 5-21
CopyingandPastingObjects 5-21
SurfaceFinish 5-23
SplittingObjectsintoComponents 5-23
Model-MaterialSettings 5-24
ChangingtheModelMaterial 5-26
ChangingtheSupportMaterial 5-26
DigitalMaterials 5-27
AssigningaModelMaterialtoObjects 5-28
CoatingObjects 5-29
PositioningObjectsontheBuildTray 5-30
AutomaticOrientation 5-30
AutomaticPositioning 5-32
ManualPositioning 5-33
ManipulatingObjectsontheTray 5-35
PositioningObjectsontheZ-Axis 5-35
ValidObjectPlacement 5-36
UsingaGridtoPositionObjects 5-37
