Large File
Manipulation
Ifyouneedtoworkwithadetailedmodelthatiscomposedofalargenumber
ofpolygons,youcanspeedupitsdisplayandmanipulationinObjetStudioby
reducingthenumberofpolygonsonthescreen.Althoughthismayreduce
theresolutiononthescreen,ithasnoaffectontheprintedmodels.
Figure5-65Objectdisplayedwithoutpolygonreduction
Figure5-66Objectdisplayedwithonlyfivepercentofitspolygons
showing
Tousepolygonreduction:
1. FromtheToolsmenu,selectOptions.
or—
FromtheObjetStudioCommandsmenu ,clickOptions.
