Objet260 User Guide 5 Using Objet Studio
DOC-37004 Rev.E 5-36
Valid Object
Placement
Youcanensurethatmodelsdonotoverlapwhenyoupositionthemonthe
buildtray,andthattheydonotextendbeyondthetray.
Toensurevalidobjectplacement:
1. FromtheToolsmenu,selectConstraintsSettings.
Figure5-39Constraints Settingsdialogbox
2. SelectDynamicchecktoidentify—
❒ invalidobjectplacementwhileplacingobjects—On Dropselected.
❒ invalidobjectplacementaftermovingobjects—While Drag selected.
❒ objectsplacedbeyondthetray’sboundaries—Outside Tray selected.
❒ objectsthatoverlap—Object Collision selected.
EvenifyoudonotuseDynamic Check whenplacingobjectsonthebuild
tray,ObjetStudioautomaticallychecksifthereisaproblemwiththe
positioningofobjectsonthetraybeforesendingittotheprinter.Youcan
alsomanuallycheckforproblemsafterpositioningobjects(see"Tray
Validation"onpage5-55).
Note: Becauseoftheuniquecharacteristicsofeachtypeofmodelmaterialand
finish,alwayscheckvalidplacementafterchangingthematerial/finish.
RememberthatObjetStudiocalculatesthespaceoccupiedbyanobject
includingthe“boundingbox”surroundingit(seeFigure5-54onpage5-47).
