Objet260 User Guide 6 Operating and Maintaining the Objet260 3DPrinter
DOC-37004 Rev.E 6-73
Warning: Broken UV lamp hazard
UVlampscontainmercury.Dealwithbrokenlampswithcaution.
l Ventilatetheroomthoroughly.
l Useprotectivegloveswhencollectingmercuryandlampcomponents.
l Removespilledmercurywithamethodthatpreventsthegenerationof
mercuryvapor,suchasasyringe,packingtapeorpaper.
l Placethebrokenlamp,mercuryandcontaminatedmaterialsinanair-
tight,non-metalliccontainer.
10.InsertthenewUVlamp/reflectorunitintothehousingnexttotheprint
block.
Figure6-112PrintblockandUVlampassembly,showingcorrect
placementofblackstrip
11.ReplacetheUVlampcoverbyinsertingitintotheslotonthebottomof
thehousing,andtightenthesecuringscrewontop.
Figure6-113ReplacingtheUVlampcover
