Insert a specimen mover plate
1. Press the Lower/Raise button to make sure that the specimen mover head is
fully raised.
2. Press the black button on the specimen mover head.
3. Insert the specimen mover plate and rotate it until the three pins are aligned with
the holes in the specimen mover.
4. Push the specimen mover plate upwards until it locks in position.
5. Release the black button on the specimen mover head.Make sure that the
specimen mover plate is securely fixed.
Adjust the height of the specimen mover plate
The following applies only when specimen mover plates are used.
1. With a specimen mover plate mounted, place a
preparation surface on the preparation disc.
2. Select the ‘thickest’ preparation surface to be used and
place it on the preparation disc. Usually, this will be SiC
Foil on an MD-Gekko disc, or SiC Paper on an MD-Fuga
disc, or an MD-Alto.
3. Place the supplied spacing disc on the preparation
surface.
A Spacing disc
44 LaboPol-30
8 LaboForce-100
