LUCAS
®
3 Chest Compression System – Service Manual
3328798-002, ©2017 Physio-Control, Inc.
Page 75 of 91
• Turn the leg on the other side; and use the Angel Shaft Tool (optional tool) or similar tool with a Hammer
to knock out the press fitted Angle Shaft, which is fitted into the Main Body.
The bottom, non-press fitted
Angel Shaft
Press Fitted Side with Key
To Next Page
