89
Technical Specications
Equipment Information
Size • Control Unit: 12�5” W × 16�5” D × 7�25” H
• Total Weight: 22�5 lbs (10�2 kg)
• Display: 8” TFT LCD, with digital touchscreen
Power Consumption 100-240VAC ~ 50/60Hz, 4A/2A maximum
Recommended
Security -
Authentication and
Encryption (when
connecting to
Hospital network)
WPA2-Enterprise (PEAP-MSCHAP v2 authentication) with AES
encryption
Wireless Transmission • Type of modulation: OFDM and DSSS
• Maximum EIRP level: 7�83 dBm
• Operating frequency range: 2403�04 MHz to 2480�54 MHz
Electrical Safety
Classication
• Class I Equipment
• No Applied Part
• Water Ingress Protection, IPX0
• Continuous Operation
Environmental
Specications
• Operating Temperature: 10 – 40°C
• Operating Humidity: 25 – 75% RH
• Transport and Storage Temperature: -18° – 60°C
• Transport and Storage Humidity: 15 – 90% RH
FCC Compliance Contains FCC ID: RYK-WUBR170GNM
This device complies with part 15 of the FCC Rules� Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) This device must accept
any interference received, including interference that may cause
undesired operation�
Battery Recycling The Batteries Directive 2006/66/EC introduces new requirements
from September 2008 on removability of batteries from waste
equipment in EU Member States� To comply with this Directive,
this device has been designed for safe removal of the batteries at
end-of-life by a waste treatment facility� Infected units should be
decontaminated before they are sent for recycling� In the case that it
is not possible to decontaminate the unit for recycling, the hospital
should not attempt to remove the batteries from waste equipment�
Continued disposal of small amounts of portable batteries to landll
and incineration is allowed under the Batteries Directive 2006/66/EC
and Member State regulations�
