Playback of Recorded Images
Within the Playback screen, the IMAGES tab on the right side of the screen allows review,
annotation, and printing of previously captured images�
1
9
8
7
5
3 62 10
4
To browse images:
1� Press the arrows on either side of the center preview screen to scroll through captured
images one at a time�
2� Press the arrows on either side of the bottom row of images to scroll through the album ve
images at a time�
3� Tap an image on the bottom panel of images 2 times to see it on the center preview
screen� Primary channel images are identied with a “P” and Secondary channel images are
identied with an “S�”
To see images on the surgical display, there are 2 options:
4� Press the CURRENT IMAGE
button to see the image from the center preview screen on
the surgical display�
5� Tap the image on the center preview screen 2 times to see the image on the surgical display�
To select images:
6� Press an image to select it� Selected images are identied by a green border� Press the image
again to deselect it�
7� Press the SELECT NONE
button to switch between Select All and Select None and select
or deselect all images in the album�
