44
Playback of Recorded Videos
Within the Playback screen, the VIDEOS tab on the right side of the screen allows review and
annotation of previously captured videos
7
6
54 3
2
1
To browse videos:
1� Press the PRIMARY button to choose Primary or Secondary and browse videos recorded on
Channel 1 (primary) or Channel 2 (secondary)�
2� Press the arrows on either side of the center preview screen to scroll through captured
videos one at a time� Each video is identied in the top left corner by the channel and order
in which it was captured� Primary channel videos are identied with a “P and Secondary
channel videos are identied with an “S�
3� Press the arrows on either side of the bottom panel of videos to scroll through the album ve
videos at a time�
4� Tap an image 2 times from the bottom panel of images to see the corresponding video on
the center preview screen�
To playback videos:
5� Press the PLAY and STOP buttons to control the video in the center preview pane
To select videos:
6� Press any video to choose it� Selected videos are identied by a green border� Deselect a
video by pressing it again�
7� Press the SELECT NONE
button to switch between Select All and Select None to select
or deselect all images in the album�
