Perform a variety of functions with the SwitchPoint Infinity 3 Control System,
such as speaking through the microphone and powering on and off the
microphones.
c. Reposition devices as necessary to maintain electromagnetic compatibility, or
disable the wireless microphone.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
conditions that this device does not cause harmful interference.
2.2 Cautions
1. Carefully unpack this device and check for damage. Refer to the standard warranty if
the device is damaged.
2. To prevent damage, follow all sterilization and disinfection instructions in this manual.
A deviation may cause damage. DO NOT STERILIZE OR DISINFECT THE
CONTROL UNIT OR THE TOUCH PANEL DISPLAY.
3. Only Stryker approved personnel can adjust, modify, and repair this equipment.
4. Do not install the unit in a location near heat sources such as radiators or air ducts, or
in a place subject to direct sunlight, excessive dust, mechanical vibration, or shock.
5. The leakage current could increase when connected to other equipment.
6. Do not position the unit such that it is difficult to disconnect the power cord.
7. Caution: Federal law (United States of America) restricts this device to use by, or on
order of, a physician.
2.3 Notes
1. Stryker Communications has verified that the SwitchPoint Infinity 3 Control System
complies with the electromagnetic compatibility requirements for medical devices as
specified in IEC 60601-1-2. RF communication equipment such as the wireless
microphone in the SwitchPoint Infinity 3 Control System, however, can still affect
other medical electrical equipment in the operating room.
2. The screen captures in this manual may differ slightly from each individual
SwitchPoint Infinity 3 setup, depending on configuration.
3. The terms “SwitchPoint Infinity” and “SPI” are used interchangeably throughout the
manual.
4. Operate the unit on 100 VAC 50/60 Hz in Japan, 120 VAC 50/60 Hz in North
America, and 100-240 VAC 50/60 Hz in other locations.
5. The nameplate indicating operating voltage, power consumption, and other
information is located next to the power entry module on the front of the SPI3 and on
the back of the SPI3-Lite.
6. This equipment uses only RoHS approved/complaint lead-free solder.
