90
26.5 SPI3 Control System Electrical and Physical
Specifications
Dimensions 317.856mm x 64.237mm x 431.8mm
(12.514” x 2.529” x 17”)
Weight* 3.7 kg (8.1 lbs)
Power Consumption** 225 VA
Input Voltage Range 100-240V 50/60Hz
Total Shipping Weight 5.0 kg 11.2 lbs
Shipping Dimensions (w x h x d) 419.1 x 165.1 x 520.7 (16.5” x 6.5” x 20.5”)
* Weight based on maximum configuration, actual weight is configuration dependent.
** Maximum power rating, actual power draw is configuration and process dependent
26.6 All-In-One Control System Electrical and Physical
Specifications
Dimensions 550mm x 360mm x 65 mm (21.65” x
14.17” x 2.55”)
Dimensions with Stand (w x h x d) 533.4 mm x 425.5-533.4 mm x 190.5 mm
(21.0" x 16.75-21.0" x 7.5")
Weight 6.9 kg (15.2 lbs)
Power Consumption Max 60 W
Input Voltage Range
100–240VAC
Total Shipping Weight 7.9 kg (17.4 lbs)
Shipping Dimensions (w x h x d) 650mm x 180mm x 610mm (25.6” x 7.08”
x 24”)
26.7 Required Equipment
Using accessories or cables other than those approved by Stryker may cause harm to
the user and/or device failure.
GGuuiiddaannccee aanndd MMaannuuffaaccttuurreerr’’ss DDeeccllaarraattiioonn -- EElleeccttrroommaaggnneettiicc EEmmiissssiioonnss
The SwitchPoint Infinity® 3 Control System is intended for use in the electromagnetic
environment specified below. The customer or the user of the SwitchPoint Infinity® 3
Control System should assure that it is used in such an environment.
