88
26
Physical and Electrical Specifications
26.1 SPI3 Environmental Specifications
Operating Conditions 10° – 40°C (50° to 104°F)
30% – 75% relative humidity
70 kPA – 106 kPA
Storage Conditions Dry-Bulb Temperature: -20° C to 50° C
(-4° to 122°F)
Relative Humidity: 10% to 90 %
(Non-Condensing)
Maximum Elevation: 3050 m (10,006.5 ft)
26.2 SPI3 Electrical and Physical Specifications
Dimensions
609 mm (24”) H x 523 mm (20.6”) W x 432
mm (17”) D
Power Consumption 570 VA
Input Voltage Range 100-240 V ~ 50/60 Hz
Weight
34 kg (75 lbs)*
Total Shipping Weight 52 kg (115 lbs)*
Shipping Dimensions (w x h x d) 914.4 mm (36.0”) H x 731.52 mm (28.8”)
W x 558.8 mm (22.0”)D
* Maximum weight depending on options
