86
CCoommmmuunniiccaattiioonn
SDC touch screen is black SDC touch screen will be black when it is configured to
work with SwitchPoint Infinity 3 in SDC remote
configuration—no action is required.
Observation Room PC is
not responding
Ensure Observation Room PC is powered up
If PC is already powered up, reboot
RRoooomm CCaammeerraa
SSyymmppttoomm
AAccttiioonn
BRC-z330 camera video
works, but control does not
Press the RReesseett button on the Room Camera page
(
see 16 Room Camera, page 63
)
Make sure that the RS-22 connection to the camera
is secure
NNoottee::
DDuurriinngg ssyysstteemm ssttaarrttuupp,, tthhee ssppllaasshh ssccrreeeenn sshhoowwss vvaarriioouuss ssyysstteemm
ccoommppoonneennttss tthhaatt aarree bbeeiinngg cchheecckkeedd.. IIff aa ffaattaall eerrrroorr ooccccuurrss,, aa ddiiaalloogg iiss
ddiissppllaayyeedd wwiitthh tthhee ffoolllloowwiinngg,, PPlleeaassee ccoonnttaacctt SSttrryykkeerr CCoommmmuunniiccaattiioonnss
TTeecchhnniiccaall SSuuppppoorrtt aatt 11--886666--884411--55666633 wwiitthh <<DDeettaaiillss ooff tthhee SSyysstteemm FFaaiilluurree>>..
PPrreessss OOKK ttoo sshhuuttddoowwnn tthhee ssyysstteemm..
IIff aann aatttteemmpptt iiss mmaaddee ttoo ccrreeaattee aa vviiddeeoo rroouuttee ssuucchh tthhaatt ttwwoo II//OO ppoorrttss rreellaatteedd
ttoo tthhee ssaammee ddeevviiccee wwoouulldd bbee iinn tthhee rroouuttee ((ee..gg..,, rroouuttiinngg tthhee HHuubb IInnppuutt ttoo tthhee
SSDDCC aanndd tthhee SSDDCC ttoo tthhee HHuubb OOuuttppuutt)),, aann eerrrroorr mmeessssaaggee iiss ddiissppllaayyeedd
ssttaattiinngg,, TThhiiss ddeevviiccee iiss aallrreeaaddyy iinn tthhee ppaatthh..
25.2.3 Connecting External Video Devices
Most SwitchPoint Infinity 3 Control System installations have extra inputs and outputs for
video. Some are terminated on the boom for easy access. One of the more common
devices connected is the fluoroscope or C-arm. There are two things to be aware of
when connecting these:
1. Older model C-arms have a small termination switch next to the BNC connection. If
you are not connecting an external device to the C-arm, the switch must be in one
position. This position puts a 75 ohm resistor across the output to properly terminate
the video. If you are connecting an external device, the switch needs to be turned off.
The wrong position will cause the video signal to be attenuated. Try both positions; it
will be obvious which is correct.
2. New C-arms have multiple outputs, one of which is scan-doubled. Scan-doubling is
an analog version of higher resolution video. This won’t display correctly on a
standard monitor or the SwitchPoint Infinity 2 Control System. On GE C-arms, the I/O
panel has three jacks with small TV icons above the BNC connector. One has twice
as many lines in it. This is the scan doubled output. Use one of the other jacks. Try all
three to determine which one works the best.
