00667788--000033--000000,, PPKKGG,, SSWWIITTCCHHPPOOIINNTT IINNFFIINNIITTYY 33 LLIITTEE
5
Control-
ler
D Power
Supply
Electrolytic Caps 1 Has multiple electrolytic
caps
E PCB and Plastic 1 • Fan removes with
three (3) screws.
• Fan disassembles by
"C" clip under label on
hub.
F Mother-
boarad
PCB, AL Heat
Sinks, Fan
1 • Removes with four (4)
screws.
• Contains multiple
electrolytic CAPs
G Daugh-
ter
Cards
PCB 3 Removes by depressing
clips and rotating out
H Battery Lithium battery 1 • Non-rechargable,
Lithium coin battery:
• Mfg: Panasonic
(Model CR2032), 3.0V
(225 mAh), Contains
Manganese Dioxide
Lithium.
I Cables Wire: Tin plated
copper
Contacts: brass or
phosphor bronze
with Tin or Tin &
Copper plating
Connector bodies:
Nylon
3 Cable assemblies
attached by nylon tie-
wraps and terminated on
either end by friction-fit
and / or snap-fit
connectors and / or
screws.
