72 Sun StorageTek 2500 Series Array Hardware Installation Guide • September 2009
FIGURE 6-4 Mixed Topology of Data Hosts Connected Directly and Through FC Switches
FIGURE 6-5 Connecting the SFP and Fiber-optic Cable to a 2540 Controller
1. Host
2. HBA 1
3. HBA 2
4. Host Port 1
5. Host Port 2
6. Controller A
7. Controller B
1. Fibre Channel Host Port
2. SFP is Inserted
3. Fiber-optic Cable is
into the SFP
into the Host Port
inserted
1
2
3
